Shree Engineering

Salient Features :

Positive & pressurized jets through washing needle for pressure cleaning at minimum usages for washing media.
Both internal & external washing ensuring absolutely & continuous ampoule / vial after sequential washing.
Acrylic top cover for clear view of washing events taking place in the machine.
On-line poly carbonates housing with P.P. replaceable filter cartridge of 5 OR 10 micron of water for best possible washing.
All contact parts of washing media are of S.S.
In the event of acrylic cover lifted during cycle operation, the machine will automatically stop and re-start from the point when cover is pushed down

Optional Features :

Note :

Washing Cycle :

Model - Rotary Bottle Washing Machine	SEMW-200
	Output/Hour*	Up to 6000 Vials. Up to 9000 Ampoules
	Power Consumption**	Main Motor	0.5HP
	Power Consumption**	Pump Two Nos.	1.0 HP x 2 nos.
	Wash Cycle	4 water + 2 Air for drain. Including 1 external wash each for water and air.
Water consumption.	200-500 Litters. per hr. Depending on Vial size
Air consumption.	20 CFM
Conveyor height.	875 mm to 950 mm
Machine Dimension	990mm (L) X 860mm (W) X 940mm (H)
Case Dimensions	1200 mm (L) x 1000 mm (W) x 1150mm (H)
Net Weight	120 kgs
Gross Weight	450 kgs.

Manual Ampoule Vial Washing Machine Shree Engineering
