Here, we of exclusive range of Bottle Unscrambler Machines which provides affirmative bottle handling, maintaining complete and gentle control over bottles at standard speed rate. This is versatile machine which is used to feed the empty bottles at high speedat the beginning of a packaging line tochange containers and present them to the packaging system for, capping, labeling, filling and various other packaging function. The user simply dumps containers into theunscrambler and machine does the rest thing. It is suitable for being used at Pharmaceuticals, Mineral Water, Cosmetics, Beverage, Food, Water, Chemicals, Household Products, and more. The Bottle Unscrambler Machine that we offer is suitable for PET, HDPE, and LDPE bottles of different neck sizes. As a highly efficient machine, it allows changing the neck sizes, based on the requirement.

Salient Features :

  • Unscrambler for uninterrupted bottle feeding
  • Simple change over for different size
  • Built in a.c variable frequency drive system
  • Automatic infeed of containers
  • Continues of linear motion of machine

Technical Specification :

Product Diameter Up to 70mm
Product height 100-250 mm
Speed Up to 200 BPM depending on botte size
Conveyor height 750 to 800 mm adjustable
Overall dimension 1200(L)X700(W)X800mm(H)
Suitable 30ml-250ml

Required utility :

Electrical 220v a.c single phase power supply
Power 1.5kw
Motors 3phase(2x0.5hp+15w)
