Linear Tunnel Type Washing Machine

Features :

High-pressure pump ensure proper wash of bottle.
Contact parts S.S. 316 Non Contact parts S.S. 304 Including the basic frame.
Suitable for Round and Flat Glass Bottle (with help of change parts).
Water re-cycling provided as per customer's SOP.

Optional Features : Flat & Round Bottle Washing Machines

For high volume container wash provided high pressure centrifugal pump
Fully functional PLC with Touch Screen for the whole operation of the machine
Quick Recipes, Batch Details, Password Protection, etc. through PLC

Note :

* Depends on container size.
** We can supply as per customer requirements.

Model - Rotary Bottle Washing Machine	SEW-120
	Output/Hour*	Up to 9000 Bottle
	No. of Pocket Across	15
	Power Consumption**	Main Motor	1 HP / 415 Volts / 50 Hz
		Pump Two Nos.	0.5 HP / 415 Volts / 50 Hz x 2 Nos
Electrical Heater		3 Kw.
Wash Cycle	4 Inner + 1 Outer + 1 Air
Machine Dimension	2740 mm (L) x 1600 mm (W) x 1675 mm (H)
Case Dimensions	2950 mm (L) x 1800 mm (W) x 1875 mm (H)
Net Weight	950 Kgs
Gross Weight	1450 Kgs
