Suitable for washing of Vials (2ml to 30ml) (dia. 14mm to 35mm)
All Contact parts made out from SS 316
Entire frame covers & non contact parts made out from SS 304
Needles enter in to the container during washing cycle to meet cGMP requirement
Low water consumption
Quick change over of parts for other size of containers
Complete flexibility with user for washing cycle
Machine provides 4 water washes, 3 air washes and 1 silicon (Optional)
Operation
Containers feed from the decartoning station (optional) are received on a unscrambler through Visual Inspection Unit (optional). An infeed worm inverts container as neck down position and feeds them through specially design indexing device. The device carries the container forward and stops.
Nozzles carrier enters into the container and activates the jet of water/air. The air/water flow is deactivated after the washing cycle is over.
Device gets indexing for next wash.
A separate pumping station (optional) gives the right quantum of water at the desired pressure.
In the absence of separate pumping station we can provide the recirculation &silicon sing system on request.
Washed container are again inverted to neck upward position to collect in trays/directly feed to tunnel.
